Description
Technical Parameters
Pixel Pitch: 1.875mm
LED Module Size: 240*240*15mm
LED Panel Size: 480*480*63mm(18.9'' x 18.9'', 2.48'' in depth)
LED Panel weight: 5.2kg (11.46lbs)
E480 P1.875 indoor LED display, is considerred as one of the best options for indoor commercial advertising, for example, shopping malls, airports, schools, meeting rooms, etc.
Key Product Features：
1. Full Front service Design
2. NOVA Star and Color Light optional, mult-language supported
3. Mini data receiving card, power supply dual backup design available
4. Smart Module with memory chip available, for calibration data storage
5. quick Lock System
6. Quick disassembly design
7. Double backup design of power signal among panels
8. 240mm*240mm LED Module, power supplies, all are able to be front and rear serviced
| ITEMS | PARAMETERS | |
| LED Configuration | SMD1010 | |
| Pixel Pitch（ mm） | 1.875 | |
| Module Resolution (dots) | 128*128 | |
| Panel Resolution (dots) | 256x256 | |
| Pixel Density（ dots /m²） | 284,444 | |
| Module Size（W x H x D）/( mm) | 240x240x15mm | |
| Physical | Panel Dimension（W x H x D）/( mm) | 480x480x67mm |
| Parameters | Panel Material | Die-casting Aluminum |
| Panel Module Composition (W x H) | 2x2 | |
| Panel Weight (Per/ kg) | 5.5kg | |
| Module Weight ( Per/kg) | 0.58kg | |
| Color processing (Bit) | 14 | |
| Grey Level | 16384 | |
| Optical Processing | Refresh Rate（Hz） | 1920-3840Hz |
| Driving Mode (scan) | 1/24 scan | |
| Brightness（ nit） | 600-800nit | |
| Viewing Angle（ H/V） | 160/160 | |
| Input Voltage（V） | AC220V±10% | |
| Electrical | Input Power Frequency（Hz） | 50/60 |
| Parameters | Max Power（W/m²） | 700W/m² |
| Average Power（ W/m²） | 230W/m² | |
| Storage Temperature (℃） | ―10 - 50 | |
| Operating Temperature（ ℃） | ―0 - 40 | |
| Storage Humidity（RH） | 10%~90% | |
| Operating Environment | Operating Humidity（RH） | 10%~90% |
| IP Rating | IP30, indoor use only | |
| Lifetime（hrs） | 100000 | |
| Panel Installation Method | Fixed, full front service | |
| Panel Maintenance Method | Front/Rear Maintenance | |
