P2.5 LED Screens

This product has been used for many fields such as stage, bar, entertainment TV stations and so on, it has been shown the unique artistic charm and aesthetic feeling of space imagination. The product is convenient to install, and easy to connector by Neutrik or similar brand connectors. Now it...

Chat Now

Product Details




P2.5 indoor LED Screen

● Pixel pitch: 2.5 mm

● Pixel config.: 3 in 1 1515 SMD

● Brightness: 600-1000 adjustable

● Refresh rate: 1920Hz / 2880Hz /3840 Hz

● module dimension: 320×160 mm


This product has been used for many fields such as stage, bar, entertainment TV stations and so on, it has been shown the unique artistic charm and aesthetic feeling of space imagination. The product is convenient to install, and easy to connector by Neutrik or similar brand connectors. Now it has become one of the most popular choices for indoor advertising.

High video quality, suitable for LED screens more than 5 square meters.
Cost effective, affordable for budget option. Of similar video quality, the cost of P2.5 is around 40% lower than that of P2.0 LED screen.




● Robust design, each SMD is well protected by the plastic masks.

Nowadays, pixel pitch 2.5mm, 2mm, or even less, are getting very popular in the market; and more and more people are getting to realize that, pixels are exposed without protection of plastic mask, during installation, the SMDs at edge, are damaged frequently. And for such pixel pitches, it is extremely difficult to repair.
By P2.5 LED Screen, it is as robust as P4, but much higher resolution. The impressive video quality is highly appreciated by lots of applications.



Features
1. slim cabinet: Light weight, excellent cooling effect
2. High definition, and good stability
3. Good color uniformity and high contrast ratio with black led lamp
4. Wide viewing angle: 140° on both vertical and Horizontal


Pixel Pitch

2.5 mm

3 mm

LED Type

SMD2020

SMD2121

Configuration

1R1G1B

1R1G1B

Module Size

160*160 mm

192*96 mm

Pixel Density

160000 pixel/㎡

111111 pixel/㎡

Refresh Rate

≥ 1920Hz

≥ 1920Hz

Gray Scale

16 Bit

16 Bit

Brightness

600-1200 cd/㎡

≥ 1200 cd/㎡

Scan Way

1/32

1/16

Frame Rate

50HZ~60HZ

50HZ~60HZ

Viewing Angle

H:140°, V:140°

H:140°, V:140°

Cabinet Resolution

256*256 Dots

256*192 Dots

Cabinet Size

640*640*110mm

768*576*110mm

Cabinet Weight

13Kg

18Kg

IP Rating

IP31

IP31

Max.Power Consumption

600W/Panel

590W/Panel

Avg.Power Consumption

200W/Panel

195W/Panel

Control System

Nova/Linsn/Dbstar

Nova/Linsn/Dbstar

Working-Temperature

'-20℃~60℃

'-20℃~60℃

Working Humidity

10%~90% RH

10%~90% RH

Input Voltage

AC 110~220 V (±5%)

AC 110~220 V (±5%)

Blind spot rate

≤0.01%

≤0.01%

MTBF

35000 Hour

35000 Hour

Lifespan

100000 Hour

100000 Hour
